Abus TVIP81000 - Description of the connections

22
English
8
9
3. Description of the connections
No.
Description
1
Network cable
2
Audio
3
Alarm output
4
Alarm input
5
RS-485
6
BNC
7
Power supply
8
Slot SD card (not used)
9
Power LED
Please note that the connections for TVIP81000/TVIP81100/TVIP82000/TVIP82100 are all
identical.
1
RED AC24V
YELLOW/GREEN
BLACK AC24V
9, ( 2'
2
3
6
7
4
5
