ADDING MORE FANS
B-SERIES CONTROLLER
Smart controllers for B-Series models with EC motors can support two fans of any size. The two
EC-motor fans must be plugged in to an outlet to power the fans and controller. See image below.
The smart controller for the CLOUDLINE B-Series
has an additional port so that you can add an
A-Series fan to power and control two fans together.
Please see below for limitations.
Dual Connection
CLOUDLINE A4/B4 CLOUDLINE A6/B6
MOLEX ADAPTER
Use the included UIS to 4-pin Molex adapter to connect your fan to your T-Series controller. Plug
your fan's UIS connector into the adapter. Then plug the adapter into your controller.
