9
INSTALLATION
STEP 2
Remove the motor box from the flange bracket.
Remove the wind circle between the motor box
and the intake flange.
STEP 1
Unscrew the bolts on both sides from the
plastic rings using a Philips screwdriver.
MOUNTING
