STEP 3 – Assemble Cross Bar to Support Legs
➢ Attach Cross Bar (# A7 and #A9) to the outer sides of Legs (# A5). Secure using B1, B6, B4 and B3
as shown in below. When assembling #A9, please assemble so the 2 extra holes that are on
A9 is located towards the front of the swing set as these holes will be used to attach the slide
in later steps (Step 14)
➢ Attach Cross Bar with foam (#A8) to the outer sides of Legs (#A6), Secure using B1, B6, B4 and B3
as shown in below.
REMINDER: Please note that A9 has two extra holes that will be used for connection to the slide in later
steps. These holes must be located towards the front of the swing set where the slide will go down to avoid
the risk of entrapment.
