AREA OF INSTALLATION – GLIDE RIDE
STEP 4 – Assemble Glide Ride
➢ Place Seat-Glide (#L2) to Leg-Glide (#L1) between. Secure using N9, N12 and N10 as shown in
below.
Part#
Qty
Hardware#
Qty
L1
2 PCS
N9
2 PCS
L2
1 PC
N12
4 PCS
N10
2 PCS
