ACADEMY MSC-5576 - Page 28

AREA OF INSTALLATION - SWING SEAT
Step 7 - Swing Seat assembly
➢ Connect the swing seat to the chains by inserting J1 through K1 as shown in Diagram A.
➢ Connect swing set chains to the top bar by inserting J3 through A2. Secure with J8 and J6 as
shown in Diagram B.
➢ Repeat the same process for both sets of swings.
Part#
Qty
Hardware#
Qty
J1
4 PCS
J6
4 PCS
K1
2 PCS
J8
4 PCS
