Step 11 - Slide assembly (continued)
➢ Insert Slide Leg Tube (X3-N) into X1-N and X2-N as shown. Align the holes and hold in position.
➢ Connect the Slide Top Support Bar (X4-N) onto the Slide Supports (X1-N and X2-N) and secure using
Z1, Z6, Z3 and Z5 as shown in below.
Part#
Qty
Hardware#
Qty
X1-N
1 PC
Z1
2 PCS
X2-N
1 PC
Z6
2 PCS
X3-N
2 PCS
Z3
2 PCS
X4-N
1 PC
Z5
2 PCS
