Step 12 - Slide assembly (continued)
➢ Connect Slide Ladder Steps (X6) to Slide Supports (X1-N and X2-N). Secure both sides using Z8, Z6
and Z4 as shown in below.
Part#
Qty
Hardware#
Qty
X6
2 PCS
Z8
4 PCS
Z6
8 PCS
Z4
4 PCS
