Step 13 - Slide assembly (continued)
➢ Push the slide (Y2) down and combine with the Slide Top Support Bar (X4-N) as shown below.
➢ Secure Slide (Y2) to both sides to the leg tubes using Z2, Z6, Z6 and Z4.
☺ Helpful Hint: Make sure the Slide (Y2) is securely attached in place.
Part#
Qty
Hardware#
Qty
