ACADEMY MSC-5576 - Page 35

Z2
2 PCS
Z6
4 PCS
Z4
2 PCS
Step 14 – Attach the slide to the swing set
➢ Connect the assembled slide to the swing set frame. Place Plastic Connector (Y1) between A7 and
X1-N and secure together using Z7, Z6, Z3 and Z5 as shown below.
Part#
Qty
Hardware#
Qty
Y1
2 PCS
Z7
2 PCS
Z6
2 PCS
Z3
2 PCS
