7. PROGRAMMING THE ELECTRONIC DRIVER
Install the programming software, following the instructions of the wizard.
Connect the programming interface to a PC using the serial cable supplied with the hardware.
Power on the programming interface using the AC/DC adapter supplied with the hardware.
Connect the FDC1 electronic driver to the programming interface using the double RJ11 cable
supplied with the hardware.
Run the programming le FDC.exe.
From the top menu, load an existing conguration and go to step 9, or go through step 7.
Select the running mode, options and parameters, between:
Select the battery protection mode and the protection parameters from:
1.
2.
3.
4.
5.
6.
7.
8.
7.1
8.1
8.2
7.2
7.3
7.4
Standard mode.
Smart Speed® mode. Select maximum xed speed or external switcher connected to
SPI and proceed as described in 7.1.1 or 7.1.2 respectively.
Sleep and Sleep Energy saving modes. Select maximum xed speed or external
switcher connected to SPI and proceed as described in 7.1.1 or 7.1.2 respectively.
Slave mode
Internal protection: choose between normal and special voltage systems.
External protection. Protection values are shown in Table 3 of point 5. External
protection is incompatible with external speed selection (step 7.2).
8.1.1
7.1.1
7.1.2
8.1.2
For normal voltage systems, enter cut-out, cut-in and maximum voltage
values for every voltage system, accounting for the limits shown in Table 2
of point 5.
For special voltage systems, enter cut-out, cut-in and nominal and maximum
voltage values accounting for the limits shown in Table 2 of
point 5.
Select maximum xed speed and enter a value within 1,500 and 3,500 r.p.m.
as described in point 6, if desired select speed limited by available battery
voltage, or
Select external switcher connected to SPI and enter low and high speed
values within 1,500 and 3,500 r.p.m. as described in point 6. External speed
selection is incompatible with external battery protection (step 8.2).
In order to program the electronic driver FDC1, a personal computer together with the FDC
programming package are required (provided by ACC under request). To this purpose, perform the
following steps:
September 2006 9
GD30FDC User Manual
