BRANCH CIRCUIT BREAKER REQUIREMENTS
240 Volts 4 Wire System 30/50 Amp 2 Pole Breaker
USE COPPER CONDUCTOR ONLY. #6 AWG WIRE
120 Volts 3 Wire System 20 Amp 1 Pole Breaker
CAUTION: A new breaker must be used for a new spa installation. Do not use
an existing or used breaker.
GFCI: All spa installations must be protected by a GFCI. If your spa control box
does not include an integrated GFCI then you must use a GFCI breaker per Na-
tional Electrical Code requirements.
120/240 Volt Conversion. All spas are shipped configured for 240 volt (4
wire systems). Please check the nameplate on the control enclosure to identify
the type of system in your spa. If the nameplate indicates a 120/240 Volt type
system, then it is possible to convert the spa to 120 volt operation.
30/50 Amp Conversion. Some homes may have limited power service. It is pos-
sible to operate a 240 volt spa system using a 30 amp breaker. Connect 240 volt
power to the system as previously described, then set it to operate in the low
power mode.
120 or LOW POWER CONVERSION
-Press the UP and DOWN arrows simultaneously.
-Press UP arrow and go to Code U7 press SET. U7 will change to ‘1’
-Press UP arrow and go to Code U8 press SET. U8 will change to ‘1’
-Press UP arrow and go to Code P3 press SET. P3 will change to ‘1’
-Press UP arrow and go to Go to code SEND and press SET (Ignore and do not
change the rest of the codes as the can alter the spa settings).
If P3 is “0” = High power
If P3 is “1” = Low power
120V CONVERSION ONLY
Install jumper wire across “Neutral Terminal” and “Line 2 Terminal” at the main
Terminal Block.
Note: Only experienced service personnel should perform conversions.
Improper modifications may cause damage to the control system
and/or the attached heater and pump motors.
U S E R O P TI ON S
Error Messages
S E L F DI A G NO S T IC C OD E S
To Save Changes And Exit Go To Code SEnd
To Exit Without Saving Changes Go To Code CAnC
