Read response time 0.3 seconds
Read direction Bi-directional
Construction Integrated into keyboard housing
MTBF 100,000 operating hours
Read head life 500,000 passes
Diagnostics Internal self test upon power up
Red and Green LED for data read and audible
sounder.
2.3 Auxiliary RS232 Interface Port
Data Input Standard ASCII RS232
Configurable settings
9600 Baud,
7 Bit or 8 bit
None or Even Parity
One Stop
The auxiliary R232 port connection of industry standard external OCR reader, decoded barcode
scanner or RS232 device. A +5 Volt, 150mA power supply is available on pin 9 of a 9 PIN D type
connector
2.4 Integrated ‘Dual Illumination’ OCR Reader
Data Source Machine Readable Passports (MRP)
2 lines of 44 characters
Machine Readable Visas (MRV)
2 lines of 44 characters
2 lines of 36 (size II)
Machine Readable Travel Cards
