The chair
14
Footrest
Figure 3-3: Short footrest
The stairlift can be equipped with two types of footrests:
• The standard type (default);
• A short version, optional for situations in which the passage of a chair with standard footrest is hindered,
such as in the case of a narrow stairwell.
The footrest is attached to the chair frame and can be folded up.
If the seat position is raised, the footrest must be lowered so that the distance between the footrest and the stair
remain the same, but the distance between footrest and seat is increased. In this way the chair can be adjusted to
the height of the user (Tab 04 - Installation manual).
Chair folding mechanism
The seat can be folded by lifting the front of the seat until the seat is vertical. The movement is dampened by a gas
spring.
The footrest can be folded by lifting the handle at the front until the support is vertical
Unfolding can be done by moving the footrest and the seat back to the horizontal position.
