144 CHAPTER 15
Within the CTRL-Menu
01111111111111111112
1 B36 101BASS RP
OutSel Out1 L+R≤
61111111111111111154
If the selected output is monopho-
nic, then the Panorama settings
and modulations in the sound pro-
gram are inactive.
OUT 1 L The left jack of dual Output 1 (mono)
OUT 1 L+R Both jacks of dual Output 1 (stereo)
OUT 1 R The right jack of dual Output 1 (mono)
OUT 2 L The left jack of dual Output 2 (mono)
OUT 2 L+R Both jacks of dual Output 2 (stereo)
OUT 2 R The right jack of dual Output 2 (mono)
OUT 3 L The left jack of dual Output 3 (mono)
OUT 3 L+R Both jacks of dual Output 3 (stereo)
OUT 3 R The right jack of dual Output 3 (mono)
AUX 1 L The left channel of internal Aux 1 (mono)
AUX 1 L+R Both channels of internal Aux 1 (stereo)
AUX 1 R The right channel of internal Aux 1 (mono)
AUX 2 L The left channel of internal Aux 2 (mono)
AUX 2 L+R Both channels of internal Aux 2 (stereo)
AUX 2 R The right channel of internal Aux 2 (mono)
