• Connect the XR112 Radar Sensor
Board to the XC112 Connector Board
using the provided flex cable.
• Connect the Raspberry Pi3 to the
XC112 Connector Board.
• Also, connect mouse and keyboard in
the same way as on previous page.
Assemble the HW XC112/XR112
5
Four XR112
connected to XC112
Flex Cable
USB Mouse
USB Keyboard
Monitor
To Next Page
