Drainage Option
Option 2: Gravity Drain Hose
1.
Hose is not provided, so user shall prepare it in advance. [Size: The hose thread should have an outer
diameter of 1 1/16 inches (1.0625 inches or 27.0mm), and a pitch of 11.5 TPI.]
2.
Remove bucket from the unit as indicated in the instruction in option 1.
3.
Thread the drain hose onto the nozzle and make sure it's securely locked
4. Replace the bucket in the unit. Make sure the drain hose goes through the bucket's drain hole and
is placed downward. Lead the hose to the floor drain and then cove the hole with the cover plate.
Note that drain hose should not be pressed, otherwise water can not be drained out.
NOTICE: When you want to take off the drain hose, prepare a receptacle to collect water from the nozzle.
