ACE COMPUTERS VS-U660I - Component Identification and Views

9/28/2022
ACE120
8
Representative Desktop Component Layout
Please note the illustration below is a representative sample of the Vision Series, your PC may
include additional components or variations of this family configuration.
Figure 1
Heat Sink
Fan
Processor
Memory (2-
4 DIMMS)
Power Supply
Case Fan
HDD Storage
Device
Optical Drive
Graphics
Card
M.2 SSD
Storage
Device
Motherboard
