Series SR90
Event action: ON-OFF action
Hysteresis: 1~999 units
Standby action: Selectable from the following 4 types
EV1 and EV2: 1 Without standby action.
2 Standby when power is applied.
3 Standby when power is applied and
when SV value in execution is changed.
4 Control mode without standby action (No
alarm is output at the time of abnormal
input).
Output type/rating: Contact (1a × 2 points common)/240V AC
1A (resistive load)
Output updating cycle: 0.25 seconds
Heater break/heater loop alarm (option)
Break/loop detection only for OUT1 (Selectable when output type is
contact or SSR drive voltage)
Current capacity: 30A, 50A to be designated when CT is
ordered.
Alarm action: Heater current is detected by external CT
provided as an accessory.
When heater break is detected while control
output is ON=Alarm output ON
When heater loop alarm is detected while
control output is OFF=Alarm output ON
Current setting range: OFF, 0.1~50.0A (Alarm action is stopped
by setting OFF)
Setting resolution: 0.1A
Current display range: 0.0~55.0A
Display accuracy: ±2.0A (Sine wave at 50Hz)
Minimum time to identify action:
0.25 seconds (every 0.5 seconds) common
to ON and OFF
Alarm retention mode: Selectable from lock (to retain) and real
(not to retain).
Standby action: Selectable from without (OFF) and with
(ON).
Sampling cycle: 0.5 seconds
Isolation: CT input not insulated from system and
other inputs but insulated from the others.
Set value bias (option)
Setting range: −1999~5000 units
Action input: Non-voltage contact or open collector (level
action) about 5V DC, 1mA maximum
Minimum level retention time:
0.15 seconds
Isolation: Action input not insulated from system and
other inputs but insulated from others
Communication function (option)
Type of communication: RS-232C, RS-485
Communication system: RS-232C 3-line type half duplex system
RS-485 2-line type half duplex system
{RS-485 is of half-duplex multi-drop (bus)
system}
Synchronization system: Start-stop synchronization system
Communication distance: RS-232C The longest: 15 m
RS-485 The longest 500 m (depending on
conditions)
Communication speed: 1200, 2400, 4800, 9600, 19200 bps
Data format: 7 bits, even parity, 1 stop bit or
8 bits, non-parity, 1 stop bit
Communication address: 1~255
Communication memory mode:
EEP/RAM/r_E
Communication BCC: Add/Add two's cmp/XOR/None
Communication delay time: 1~100 (× 0.512 msec)
Communication code: ASCII code
Communication protocol: Shimaden's standard protocol
Number of connectable instruments:
RS-232 1
RS-485 up to 31
Isolation: Communication signals insulated from
system, each input and each output.
Analog output (option)
Number of output points: 1 point
Type of analog output: Selectable from measured value, target
value (SV in execution), control output 1
and control output 2.
Output signal/rating: 4~20mA DC/Maximum load resistance 300Ω
0~10V DC/Maximum load current 2mA
0~10mV DC/Output resistance 10Ω
Output scaling: Measured value, target value: Within
measuring range (inversed scaling possible)
Control output 1 and 2 0.0~100.0%
(inversed scaling possible)
Output accuracy: ±0.3% FS (with respect to displayed value)
Output resolution: Approx. 0.01% (1/10000)
Output updating cycle: 0.25 seconds
Isolation: Analog output insulated from system and
inputs but not insulated from control output
except contact output.
General specifications
Data storage: Non-volatile memory (EEPROM)
Environmental conditions for instrument operation:
Temperature: −10~50˚C
Humidity: 90% RH or less (no dew condensation)
Height: 2000m from the sea level or lower
Category: II
Degree of pollution: 2
Storage temperature: −20~65˚C
Supply voltage: Either 100-240V AC±10% 50/60Hz or
24V AC/DC±10% to be designated.
Power consumption: SR91: 100-240VAC 11VA maximum for
AC; 6W for DC 24V; 7VA for AC 24V
SR92, SR93 and SR94: 100-240VAC
15VA maximum for AC; 8W for DC
24V; 9VA for AC 24V
Input/noise removal ratio: 50 dB or higher in normal mode (50/60 Hz)
130 dB or higher in common mode
(50/60 Hz)
Applicable standards:
Safety: IEC1010 and EN61010-1
EMC: EN61326
Insulation resistance: Between input/output terminals and power
terminal 500V DC 20MΩ or above;
Between input/output terminals and
protective conductor terminal 500V DC
20MΩ or above
Dielectric strength: Between input/output terminals and power
terminal 2300V AC/minute; Between
power terminal and protective conductor
terminal 1500V AC/minute
Protective structure: Only front panel has dust-proof and drip-
proof structure equivalent to IP66.
Material of case: PPO resin molding
(equivalent to UL94V-1)
External dimensions:
SR91: H48 × W48 × D111 (Panel depth: 100) mm
SR92: H72 × W72 × D111 (Panel depth: 100) mm
SR93: H96 × W96 × D111 (Panel depth: 100) mm
SR94: H96 × W48 × D111 (Panel depth: 100) mm
Mounting: Push-in panel (one-touch mount)
Panel thickness: 1.0~4.0 mm
Panel cutout: SR91: H45 × W45 mm
SR92: H68 × W68 mm
SR93: H92 × W92 mm
SR94: H92 × W45 mm
Weight: SR91: Approximately 170 g
SR92: Approximately 280 g
SR93: Approximately 330 g
SR94: Approximately 240 g
ITEM
CODE
SPECIFICATIONS
SERIES SR91-
INPUT
Multi input
CONTROL OUTPUT (1)
POWER SUPPLY
REMARKS
OPTION
Control output (2)
Heater break alarm
Analog output
Communication
Set value bias
EVENT OUTPUT (OPTION)
4
8
6
Y-
I-
P-
V-
90-
08-
0
1
N
Y
I
P
V
1
2
8
3
4
6
5
0
9
MPU-Based Auto-Tuning PID Digital Controller, DIN H48 W48 D110mm
Thermocouple: B, R, S, K, E, J, T, N, PLII, Wre5-26 {U, L (DIN 43710)}
R.T.D.: Pt100
Ω /JPt100 Ω
Voltage: -10~10, 0~10, 0~20, 0~50,
10~50, 0~100mV DC
Current (mA): 0~20, 4~20mA DC
Receiving impedance: 250
Ω
Voltage (V): -1~1, 0~1, 0~2, 0~5,
1~5, 0~10V DC
For voltage and current input:
Scaling Possible
Range: -1999~9999
Span: 10~5000
Note: Inverse scaling
is not possible
Contact: 1a, Contact capacity: 240V AC 2.5A/resistive load
Proportional cycle: 1~120 sec.
Current: 4~20mA DC
Load resistance: 600
Ω max.
SSR drive voltage: 12V 1.5V DC/30mA max.
Proportional cycle: 1~120 sec.
Voltage: 0~10V DC
Load current: 2mA max.
100~240V AC 10%, 50/60Hz
24V AC/DC 10%, 50/60Hz
None
Contact output (2a) Ev1, Ev2: 240V AC 1A/resistive load
None
Contact: 1a, Contact capacity: 240V AC 2.5A/resistive load
Proportional cycle: 1~120 sec.
Current: 4~20mA DC
Load resistance: 600
Ω max.
Proportional cycle: 1~120 sec.
SSR drive voltage: 12 1.5V DC/30mA max.
Load current: 2mA max.
Voltage: 0~10V DC
Current setting range: 0.1~30.0A (with CT 30A)
Current setting range: 0.1~50.0A (with CT 50A)
when control output (1)
Note: Avaialble only
output is selected.
is Y or P and when event
Current: 4~20mA DC, Load resistance: 300
Ωmax.
Voltage: 0~10mV DC, Output resistance: 10
Ω
RS-485
Voltage: 0~10V DC, Load current: 2mA max.
Open collector input rating: approx. 5V/1mA max.
1 point (setting range: -1999~5000), Non-voltage contact or Open collector input
With (Please consult before ordering.)
Without
Note:
When you purchase a two-output type controller and use it in a one output capacity, larger overshooting or undershooting may happen as
a result of integral operation. Therefore, we recommend you to choose a one-output type.
The cause of the above-mentioned problem is that the positional relationship between the proportional band (PB) and the set value (SV)
of a one-output type controller differs from that of a two-output type.
