86
a Halliburton company
4
1
⁄2˝ Gauges
Type 1000, Grade B, (3-2-3%)
Type 2071A, Grade A, (2-1-2%)
Ashcroft
®
Type 1000 gauges have
a black steel case and ring with a
glass window. These gauges are ap-
propriate for general industrial appli-
cations and can be customized to
complement your equipment.
Ashcroft contractor gauges (Type
2071A) are lightweight, highly sensi-
tive and accurate. These gauges are
designed to meet the needs of
HVAC
and plumbing contractors, and are
tested against strict industry specifi-
cations. The aluminum case provides
corrosion resistance.
The patented Power
Flex
move-
ment, in both Types 1000 and
2071A, provides the shock resis-
tance needed for rough treatment.
True Zero indication reduces the
potential risk of installing a damaged
Reference Bulletin CG-10/21
MADE IN U.S.A.
Type 2071A
Contractor
gauge shown
• Type 2071A contractor gauge
offers aluminum-back flange case
(black), with attractive chrome-
plated steel ring
• Type 1000 gauge offers black
steel case with black ring and
glass window
• Adjustable pointer is standard
on contractor gauges
• Patented PowerFlex™ movement
with polyester segment
• True Zero™ indication, a unique
safety feature
GAUGE SPECIFICATIONS TYPE 1000 TYPE 2071A
Size: 4
1
⁄2˝4
1
⁄2˝
Case: Black-painted steel Aluminum with back flange, painted black.
Ring: Black-painted steel, friction fit Chrome-plated steel, friction fit
Window: Glass Glass
Dial: Black figures on white background Black figures on white background
Pointer: Black, aluminum Adjustable, black, aluminum
Bourdon tube: Bronze, soldered Bronze, soldered
(siphon required for steam service)
Movement: Patented Power
Flex
with polyester segment Patented Power
Flex
with polyester segment
Socket: Brass Brass
Connection:
1
⁄4 NPT lower
1
⁄4 NPT lower
Ranges: Vacuum through 600 psi and compound Vacuum through 600 psi and compound
Operating temperature: –40°F to 150°F –40°F to 150°F
Options:
Case color other than black
Plastic window (PD)
Chrome ring (13)
FlutterGuard (SF)
Adjustable pointer (AP)
Nickel-plated socket (NP)
Customized dials
Throttle plugs: 0.007˝, 0.013˝, 0.020˝,
0.063˝ orifices
Special calibration on application
Case color other than black
Plastic window (PD)
Nickel-plated socket (NP)
FlutterGuard (SF)
Black steel ring
Customized dials
Throttle plugs: 0.007˝, 0.013˝, 0.020˝,
0.063˝ orifices
Special calibration on application
TO ORDER THESE TYPE 1000/2071A GAUGES:
Select: 45 W 2071A 02L 300 #
1.Dial Size: 4
1
⁄2˝
2.Patented Power
Flex
™ Movement
3.Case Type Number: 2071A
4.Connection Size/Location:
1
⁄4 NPT lower
5.Range: 300 psi
gauge on your equipment.
FlutterGuard™ is available to
eliminate pointer flutter and extend
gauge life.
Consult factory for guidance in product selection
Phone (859) 986-9333, FAX 1-800-282-3732 or
visit our web site at www.ashcroft.com
