LABEL OF INDIVIDUAL COMPONENTS
Inner mouthpiece knob
Mouthpiece slot (Inner mouthpiece)
Dot Matrix LED display
5 pin USB charging port
Power button
Exhalation outlet
(Pay attention to do not block it when measuring)
6 2
3
1
4
5
1
2
3
4
5
6
