54
Sensor High resolution acetone gas sensor
Measurement unit PPM (Parts Per Million)
Detection Range 0.00 up to 99 PPM
Error rate
Less than 5ppm: +/- 0.5ppm
At or above 5 ppm: +/- 10%
Analyzing time Within 5 seconds
Dimension 110 x 53 x 19 mm (L x W x H)
Weight 74 g (battery included)
Power Supply
1 piece 3.7V Li-ion battery (rechar-
geable up to 200 times, fully loaded
with energy for up to 50 tests), USB
port 5V more than 500mA
Working Temperature 10°C up to 40°C
Storage Temperature 5°C up to 50°C
Calibration / Sensor
Replacement Cycle
Sensor Replacement Cycle:
Sensor replacement is necessary
after 1 year or after 300 tests
(whatever comes first). For a
calibration service you can send
the device to ACE Instruments
(see www.ketoscan.de).
Cerificates
US FDA Class 1
CE / KC / FCC
*The technical data are subject to change without prior notice
for functional improvements.
TECHNICAL DATA*
