9
English
Bottom view
# Item Description
1Memory
compartment
Houses the computer's main memory.
2 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the opening of
the fan.
3 Battery release
latch
Unlatches the battery to remove the battery
pack.
4 Battery bay Houses the computer's battery pack.
5 Battery lock Locks the battery in place.
4
