77
English
To set up the antenna:
1 Push gently at the top until the bottom section pops out.
2 Pull the bottom up until it is positioned at 90 degrees to the antenna body.
3 To ensure good reception, the antenna can be positioned on top of your
notebook display using the special clip, as shown below.
4 Extend the antenna to improve the quality of the reception.
Note: The antenna is only compatible with DVB-T digital TV
systems.
A magnet located on the base of the antenna unit also allows you to fix it firmly
onto a metal surface for better stability and reception.
Warning! Do not place the magnet near the hard disk drive of
your computer. Doing so may damage the drive and/or data.
2
1
3
