11
Specification
Screen
Size 15” CRT
Dot Pitch (mm) 0.28
Surface Non –glare
Viewable Image Area 260 x 195
Input Signal
Video Sync. RGB Analog 0.7Vp-p/75 Ohm
Separate H/V,TTL(+/-)
Scanning Frequency
Horizontal (KHz) 30-70
Vertical (Hz) 50-120
Max. Resolution 1280 x 1024
Signal Cable
15-pin mini D-sub
Power
Consumption Max. 75 W
Power Supply
100 - 240VAC
50/60Hz
Power Management Complies with EPA Energy Star ,VESA,
Nutek
Display Modes
Preset 6
By User 14
Operating
Operating Temperature 0-40°C
Relative Humidity 10-90 %
Dimensions (L x W x H)
382 x 360 x 367 (mm)
Weight
Unpacked 12.5 Kgs (27.56 lbs)
Packed in box 14.5 Kgs (31.97 lbs)
