35
MONITOR
CABLE
Accessory Cable,D-
Sub,BLACK
32F30180
03
Picture Part name
Description Vendor Part
No.
STAND
BASE
Seat Assy,A201P1-H01
40-D006345
LCD
FRONT
BEZEL
Bezel Assy,A201P1-H01
40-D006354
LCD BACK
COVER
Rear Assy,A201P1-H01
40-D007564
LCD STAND
NECK
Stand Assy,A201P1-H01
40-D006340
Hinge Cover
Cover Hinge,A201P1-
H01
40-D006346
PCBA
COVER
Cover AD Assy,A190A2
41-D003772
