Package contents
LCD monitor
Power cord
Audio cable
VGA cable
DVI cable
(Optional)
User's Guide (CD)
Quick Start Guide
Installation instructions
Assembling the monitor
1. Position the monitor on top of the base. 2. Connect the base into the neck of the monitor
along the track.
Detaching the monitor
If you need to detach the monitor for repackaging, the monitor and base must be separated in order to fit
in the carton.
To detach the monitor:
1. Unplug the AC power cord to make sure the power is off.
2. Pull the 4 hooks on the bottom side of the base and hold.
3. Separate the monitor and base.
Important
When separating the monitor and base, find a clean, flat surface to place the monitor on and place a clean
dry cloth under the monitor to protect it further. After removing the monitor from the base, pull the
monitor slightly up and away from the base and place it on the cloth.
