Machine Maintenance Procedures 3-49
Figure 3-44. Mainboard Recycling
IMPORTANT:
+
Circuit boards >10 cm² must be recycled. Follow local regulations for
disposal.
PCH Heatsink Installation 0
1. Install PCH heatsink (C) on mainboard. Refer to Figure 3-38.
2. Secure two (2) captive screws (A) to mainboard. Refer to Figure 3-43.
3. Install mainboard.
To Next Page
