Acer Aspire 4738 User Manual

Chapter 3 107
Replacing the USB Board
1. Place the USB board onto the chassis.
2. Replace one (1) screw to secure the USB board.
3. Connect and lock the USB FFC to the USB board. Repeat for the mainboard connector.
Step Size Quantity Screw Type
USB Board
Assembly
M2.5*4.0 1

Acer Aspire 4738 Specifications

General

Processor	Intel Core i3 / i5
RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.2 kg (4.85 lbs)
Optical Drive	DVD-Super Multi DL drive
LAN	Gigabit Ethernet
Display	14-inch HD (1366 x 768) LED-backlit
Chipset	Intel HM55 Express
Wireless	802.11b/g/n
Webcam	Acer Crystal Eye
Card Reader	5-in-1
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm
