Your Acer notebook tour - 11
Left view
# Icon Item Description
1
DC-in jack Connects to an AC adapter.
2
USB port Connects to USB devices.
3
Power button Turns the computer on and off.
Information on USB 3.0
• USB 3.0 compatible ports are blue.
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Right view
# Icon Item Description
1
Headset/speaker
jack
Connects to audio devices (e.g.,
speakers,
headphones) or a headset
with microphone.
2
SD card reader
Accepts one Secure Digital card (SD
or S
DHC).
To remove the card, simply pull it
fro
m the slot.
The card sticks out from the side of
th
e computer. Ensure you don’t
damage your card.
3
USB port Connects to USB devices.
