Acer B173 - Page 11

Timings
The product has 26 memory modes in total. 16 modes are preset and 10 modes are user definable.
MODE NO. 1 2 3 4
RESOLUTION 720 x 400 640 x 480 640x480 640 x 480
Dot clock(MHz) 28.321 25.175 30.24 31.5
f h 31.469kHz 31.469kHz 35.0kHz 37.861kHz
H-Total ( us ) 31.78(900dots) 31.778 (800 dots) 28.571(864 dots) 26.413 (832 dots)
H-Sync ( us ) 3.813(108dots) 3.813 (96 dots) 2.116 (64 dots) 1.270(40 dots)
H-B-P ( us ) 1.907(54dots) 1.907 (48 dots) 3.175 (96 dots) 4.064(128 dots)
H-Active ( us ) 25.42(720dots) 25.422 (640 dots) 21.164 (640 dots) 20.317(640 dots)
H-F-P ( us ) 0.636(18dots) 0.636 (16 dots) 2.116 (64 dots) 0.762(24 dots)
f v 70Hz(70.087) 60Hz (59.940) 66.7 HZ (66.667) 72.809Hz
V-Total (ms ) 14.27(449 lines) 16.683 (525 lines ) 15.000 (525 lines ) 13.735(520 lines)
V-Sync ( ms ) 0.064(2 lines) 0.064 (2 lines ) 0.086 (3 lines ) 0.079(3 lines)
V-B-P (ms ) 1.112(35 lines) 1.049 (33 lines ) 1.114 (39 lines ) 0.739(28 lines)
V-Active ( ms ) 12.71(400 lines) 15.253 (480 lines ) 13.714 (480 lines ) 12.678(480 lines)
V-F-P ( ms ) 0.384(12 lines) 0.317 ( 10 lines) 0.086 (3 lines ) 0.237(9 lines)
SYNC. H/V -/+ - / - +/+ -/-
POLARITY Or -/-
SEP . SYNC Y Y Y Y
MODE NO. 5 6 7 8
RESOLUTION 640 x 480 800 x 600 800 x 600 800 x 600
Dot clock(MHz) 31.5 36 40 49.5
f h 37.500kHz 35.16kHz 37.879kHz 46.875kHz
H-Total ( us ) 26.667(840 dots) 28.44(1024 dots) 26.40 (1056 dots) 21.333 (1056dots)
H-Sync ( us ) 2.032 (64 dots) 2.00(72 dots) 3.200 (128 dots) 1.616 (80 dots)
H-B-P ( us ) 3.810 (120 dots) 3.56(128 dots) 2.200 ( 88 dots) 3.232 (160 dots)
H-Active ( us ) 20.317 (640 dots) 22.22(800 dots) 20.00 ( 800 dots) 16.162 (800 dots)
H-F-P ( us ) 0.508 (16 dots) 0.67(24 dots) 1.000 (40 dots) 0.323 (16 dots)
f v 75Hz (75) 56.25 60Hz (60.316) 75Hz (75.000)
V-Total (ms ) 13.333 (500 lines) 17.78(625 lines) 16.58 (628 lines) 13.333 (625lines)
V-Sync ( ms ) 0.080 (3 lines) 0.06(2 lines) 0.106 (4 lines) 0.064 (3 lines)
V-B-P (ms ) 0.427 (16 lines) 0.63(22 lines) 0.607 (23 lines) 0.448 (21 lines)
V-Active ( ms ) 12.80 (480 lines) 17.07(600 lines) 15.84 (600 lines) 12.80 (600lines)
V-F-P ( ms ) 0.027 ( 1 line ) 0.03( 1 line) 0.026 (1 line ) 0.021 (1 line )
SYNC. H/V - / - +/+ + / + + / +
POLARITY
SEP . SYNC Y Y Y Y
