SCALER
RTD2525LH(RTD2545L)
DVI_INPUT
D_SUB15_INPUT(R/G/B/HS/VS/SOG)
DVI-D
D-SUB15
EEPROM
EDID
24C02
EEPROM
EDID
24C02
MCU
RTD2021
DVI_IIC
D-SUB15_IIC
CONTROL BUS
TO PANEL
PANEL CONNETER
LDO
TO 3.3V
LDO
TO 1.8V
5DVCC
33VCC
18DVCC
SPEAKER
AUDIO AMP
TPA6021A4
AUDIO INPUT
EEPROM
24C16
BUTTON
BOARD
POWER
BOARD
Monitor Block Diagram
