Acer B248Y - Page 15

English
• Height Adjustment
After pressing the top of the monitor then you can adjust the height of the monitor.
2
150mm
1
• Swivel
With the built-in pedestal, you can swivel the monitor for the most comfortable viewing
angle.
60
o
60
• Monitor Pivot
Before rotating the display,lift it to the top position and then push it back to the utmost
degree. Rotate clockwise until the monitor stops at 90°.
90
o
120
1
