Acer Chromebook Spin R721T - Page 19

Disassembly Procedures 1-17
Figure 1-19. Touchpad Module Removal
4. Detach the conductive tape securing the touchpad to the top assembly (Figure 1-20).
Figure 1-20. Touchpad Module Removal
5. Remove two (2) screws securing the touchpad module in place (Figure 1-21).
Figure 1-21. Touchpad Module Removal
