Acer Chromebook Spin R721T User Manual

1-6 Disassembly Procedures
Base Cover Removal 0
1. Remove eleven (11) screws from the base cover (Figure 1-3).
Figure 1-3. Base Cover Removal
2. Starting from the right side USB slot, carefully pry the base cover to release the
latches (Figure 1-4).
3. Continue to pry all sides to release the latches (Figure 1-4).
Figure 1-4. Base Cover Removal

Acer Chromebook Spin R721T Specifications

General

Operating System	Chrome OS
Battery Life	Up to 10 hours
Wireless	802.11ac Wi-Fi
Bluetooth	Bluetooth 4.2
Ports	microSD card reader, headphone/microphone combo jack
Battery	3-cell Li-ion
