4
Right / Rear side
Note: Functions vary depending on model definition.
# Description # Description
1 Power socket
8 Monitor loop-through output
connector
2 Kensington™ lock port 9 Audio in connector
3 LAN (RJ45 Port for 10/100M Ethernet) 10 Audio out connector
4 RS232 connector 11 5V DC output connector
5 HDMI 1 connector 12 12V DC output connector
6
HDMI 2/MHL connector
13 Service connector (for firmware
upgrade)
7
PC analog signal/HDTV/component
video input connector
14
S/PDIF connector
34 5 6 7 8
911
13
1210
12
12
9 11 13
1410
