Rear side (Type A)
Note: Functions vary depending on model definition.
# Description # Description
1 Power socket 8 Composite video input connector
2 HDMI (MHL) connector 9 Audio in connector
3 HDMI connector 10 Audio out connector
4
DC 5V output (service)
11 Monitor loop-through output
connector (for VGA IN 1, VGA IN only)
5 PC analog signal/HDTV/component
video input connector
12 3D SYNC connector
6 RS232 connector
7 Kensington™ lock port
4 85 6 1071 93
4 8 953
2
43 2 55 611 8 9 10
12
