Acer H61 - Default Chapter; Table of Contents

ix
7DEOHRI&RQWHQWV
1 Features ..........................................................................1
1.1 Front Panel.............................................................................1
1.2 Rear Panel ..............................................................................2
1.3 Inside Components.................................................................3
2 Component Installation.................................................4
2.1 Opening the Housing..............................................................4
2.2 Installing a System Board.......................................................6
2.2.1 ESD Precautions ......................................................6
2.2.2 Installation Procedures.............................................6
2.3 Installing Drives.....................................................................8
2.3.1 Installing a CD-ROM Drive.....................................8
2.3.2 Installing a Drive into the 5.25-inch Drive
Bay.........................................................................12
2.3.3 Installing Drives into the 3.5-inch Drive Bay .............14
2.4 Installing Expansion Boards.................................................17
2.5 Reinstalling the Cover..........................................................19
