aci INTERFACE Series - Product Specifications

PRODUCT SPECIFICATIONS
24 VAC (+/-10%), 50 or 60Hz, 24 VDC (+10%/- 5%)
50 mA, 150 mA (3.6 VA) on pressure excursions, 180 mA (4.3 VA) on pressure
excursions (FS model)
Relay Contact Closure, Transistor or Triac
9-24 VAC/VDC @ 750
EFP2: 45s, 90s, 1 min, 2 min | EFP2 Version 2: 30s, 3min, 6 min, 8 min
MAN function = output can be varied | AUTO function = output is controlled
from input signal
24 VDC/VAC @ 1A maximum, N.O. in AUTO operation (Optional: N.O. in MAN
operation)
0-5 VDC = Output Span
Maximum 28 psig (193.06 kPa), minimum 22 psig (151.69 kPa)
750 SCIM (12.29 liters)
0-10 psig (0-68.95 kPa), 0-15 psig (0-103.43 kPa) or 0-20 psig (137.9 kPa)
2% full scale at room temperature (above 1 psig or 6.895 kPa)
3% full scale across operating temperature range (above 1 psig)
Supply valves @ 20 psig (138 kPa) main/15 psig (103 kPa) out, 750 scim.
Branch Line requires 2 in or 33.78 cm (minimum) | Min. 25 ft of 1/4” O.D. poly
branch tubing
Furnished with integral-in-barb 80-100 micron lter (Part # PN004)
Optional standard barb (PN002) with external 5 micron in-line lter (PN021)
90° Pluggable Screw Terminal Blocks | 16 (1.31 mm) to 26 AWG (0.129 mm)
0.5 Nm (Minimum); 0.6 Nm (Maximum)
1/4" O.D. nominal (1/8” I.D.) polyethylene
Removeable brass ttings for Main & Branch in machined manifold, Plugged
1/8-27-FNPT gauge port
0-30 psig (0-200 kPa)
± 2.5% Midscale (± 3.5% Full Scale)
35 to 120°F (1.7 to 48.9°C)
10 to 95% non-condensing
-20 to 150°F (-28.9 to 65.5°C)
NON-SPECIFIC INFORMATION
Supply Voltage:
Supply Current:
Digital Input Signal Source:
Digital Input Signal Level (@
Impedance):
Digital Input Rates of Change:
Manual / Auto Override Switch:
Manual / Auto Override
Feedback Output:
Feedback Output Signal Range:
Air Supply Pressure:
Air Supply Consumption:
Output Pressure Range
(Jumper Selectable):
Output Pressure Accuracy:
Air Flow:
Filtering:
Connections | Wire Size:
Terminal Block Torque Rating:
Connections | Pneumatic
Tubing Size-Type:
Pneumatic Fitting:
Gauge Pressure Range (Gauge
Models):
Gauge Pressure Accuracy
(Gauge Models):
Operating Temperature Range:
Operating Humidity Range:
Storage Temperature:
