ADVANCED PROGRAMMING
To perform ADVANCED programming it is necessary to activate
the programming by following one of the following procedures:
ACTIVATION OF PROGRAMMING
TX-PLUS1:
• Press the STOP + UP + DOWN keys
• When the LED lights up, release all the keys
• Programming is activated for 30 seconds
TX-PLUS2:
• Press the STOP + UP + DOWN keys of the channel to be
programmed
• When the LED lights up, release all the keys
• Programming is activated for 30 seconds
TX-PLUS4:
• Press and release the key relative to the channel to be
programmed, the LED will light up
• Press the STOP + UP + DOWN keys, the LED goes off
• When the LED lights up, release all the keys
• Programming is activated for 30 seconds
Note: this procedure will be the same for the programming
of all functions and will not be repeated in the following
paragraphs
NOTE: to activate the programming only 1 channel must be
selected.
Below is the list of programmable functions and the number of
corresponding flashes during the programming phase
NUMBER OF
FLASHES
FUNCTION
1 Transmitter memorization and sunshade shutter
mode selection
2 Transmitter memorization and roll-up shutter
mode selection
3 Deletion of all memorized transmitters
4 Upper position of the end-of-stroke
5 Lower position of the end-of-stroke
6 Intermediate position
7 Wind sensor intervention threshold
8 Sun sensor intervention threshold
9 Temperature level
QUICK TRANSMITTER DATA STORAGE
m CAUTION: The data storage of the first transmitter
determines the direction of motion of the motor.
m CAUTION: If the awning has a casing carry out the
data storage of the first remote control by following the
procedure “TRANSMITTER DATA STORAGE”
To store your remote controls on a virgin control unit which
drives a shutter or an awning (WITHOUT casing) proceed as
follows:
1. Supply power only to the control unit to be programmed
2. Activate the programming by following one of these
procedures
TX-PLUS1:
• Press and hold down the UP+DOWN keys until the motor
starts to move in one direction
TX-PLUS2:
• Press the UP+DOWN keys of one of the two channels until
the motor starts to move in one direction
TX-PLUS4:
• Press and release the key of the channel to be programmed,
the LED will light up
• Press the UP+DOWN keys until the motor starts to move in
one direction
3. Release the keys: the motor stops
4. Press the UP or DOWN keys according to the direction in
which the roll-up shutter was moving before it stopped:
- if the roll-up shutter was being raised press the UP key;
direction obtained: the UP key raises the roll-up shutter, the
DOWN key lowers the roll-up shutter
- if the roll-up shutter was being lowered press the DOWN
key; direction obtained: the DOWN key lowers the roll-up
shutter, the UP key raises the roll-up shutter.
5. Programming is complete
To add additional remote controls, proceed as follows:
6. Press and hold down the UP+DOWN keys of a remote control
which has already been programmed until the motor starts to
move in one direction
7. Release the keys: the motor stops
8. Press the UP or DOWN key of the new remote control
