Acoustech Elite Series - PL-300 Amplifier Panel

4
2) Volume
Control
5) Crossover
Frequency
Control
1) Sub Cable
Input
3) Phase
Switch
4) Bass Boost
Switch
6) Power
Indicator
LED Light
7) Power
Auto-On/Off
Switch
8) Crossover
from Digital
Receiver
or Sub
Switch
11) Input
Voltage
Switch
10) Power Input
9) Removable Fuse Holder
120V (U.S.A.): Use a 5 Amp, 250-volt, 5 x 20mm slow-blow fuse.
240V: Use a 2.5 Amp, 250-volt, 5 x 20mm slow-blow fuse.
PL-300 AMPLIFIER PANEL
DRAWING B - Amp Rear Panel
