3. Theory of Operation
All electrical circuitry comprising the MS-2000(M) strobe light is
enclosed within its main body case assembly. These circuits operate to
step up the battery voltage to a level sufficient to fire the xenon flash
tube. This stepped-up voltage is so timed that the flash tube will fire
between 40-60 flashes per minute.
IR filter (in
storage position),
ACR P/N 4459
Flashguard,
ACR P/N 4463
Strobe lamp
Electronics
compartment
Slide for
flashguard
ON/OFF magnetic
slide switch
Lanyard
Battery, alkaline “AA”
Battery door,
ACR P/N 9338
Blue filter (in
storage position),
not visible when
stored
Figure 1
Slide for
flashguard
