99
Outline and Dimension AWM-G-2009
Indoor Unit
Model: AWM 301/301R, A5WM 311/301R
Note: Dimension in mm
Outdoor Unit
Model: A5LC 28C/CR
Note : Dimension in mm
For M5LC / MLC 028 C/CR Only
MODEL ABCDEFGH I J KLMNOPQRST
ALC 28C/28CR A5LC
28C/28CR
855 730 328 513 182 44 93 149 101 113 603 126 164 17 47 32 3 23 73 75
Note: Dimension in mm
