Acson AWM 07G User Manual

101
Electrical Data AWM-G-2009
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 10G AWM 15G
OUTDOOR UNIT ALC 10C ALC 15C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 26 29
RATED RUNNING CURRENT A 0.11 0.13
MOTOR OUTPUT W 913
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 52 59
RATED RUNNING CURRENT A 0.23 0.26
MOTOR OUTPUT W 35 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 30.0 30.0
RATED INPUT POWER W 783 1112
RATED RUNNING CURRENT A 3.50 5.00
LOCKED ROTOR AMP. A 19 21
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R22)
MODEL
INDOOR UNIT AWM 15GR AWM 20GR
OUTDOOR UNIT ALC 15CR ALC 18CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 29 47
RATED RUNNING CURRENT A 0.13 0.22
MOTOR OUTPUT W 13 20
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 59 120
RATED RUNNING CURRENT A 0.26 0.53
MOTOR OUTPUT W 35 64
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 35.0 60.0
RATED INPUT POWER (COOLING) W 1012 1653
RATED INPUT POWER (HEATING) W 892 1493
RATED RUNNING CURRENT (COOLING) A 4.70 7.40
RATED RUNNING CURRENT (HEATING) A 4.10 6.70
LOCKED ROTOR AMP. A 24 32
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
