103
Electrical Data AWM-G-2009
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 25G AWM 301
OUTDOOR UNIT ALC 25C ALC 28C
INDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 66 71
RATED RUNNING CURRENT A 0.29 0.30
MOTOR OUTPUT W 25 40
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 124 142
RATED RUNNING CURRENT A 0.54 0.62
MOTOR OUTPUT W 75 75
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 50.0 50.0
RATED INPUT POWER W 2340 2519
RATED RUNNING CURRENT A 10.50 12.20
LOCKED ROTOR AMP. A 54 66
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R22)
MODEL
INDOOR UNIT AWM 301R
OUTDOOR UNIT ALC 28CR
INDOOR MOTOR
INSULATION GRADE CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
RATED INPUT POWER W 71
RATED RUNNING CURRENT A 0.30
MOTOR OUTPUT W 75
POLES 4
OUTDOOR MOTOR
INSULATION GRADE CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
RATED INPUT POWER W 142
RATED RUNNING CURRENT A 0.62
MOTOR OUTPUT W 75
POLES 6
COMPRESSOR
INSULATION GRADE CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
CAPACITOR mF 50.0
RATED INPUT POWER (COOLING) W 2570
RATED INPUT POWER (HEATING) W 2610
RATED RUNNING CURRENT (COOLING) A 12.30
RATED RUNNING CURRENT (HEATING) A 12.40
LOCKED ROTOR AMP. A 66
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
