Performance Data AWM-G-2009
Heat Pump (R22)
Model: AWM 301R - ALC 28CR
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 8.187 5.330 7.772 4.967 7.356 4.604 6.941 4.241 6.525 3.877 6.026 3.441
16 8.441 4.894 8.027 4.579 7.614 4.265 7.200 3.951 6.786 3.637 6.289 3.260
24
16 8.441 6.144 8.027 5.830 7.614 5.516 7.200 5.202 6.786 4.888 6.289 4.511
17 8.695 5.707 8.283 5.442 7.871 5.177 7.459 4.912 7.047 4.647 6.552 4.329
18 8.949 5.271 8.539 5.055 8.128 4.839 7.718 4.623 7.307 4.407 6.815 4.147
19 9.203 4.834 8.795 4.667 8.386 4.500 7.977 4.333 7.568 4.166 7.078 3.966
20 9.456 4.395 9.037 4.266 8.617 4.136 8.198 4.007 7.779 3.877 7.276 3.722
28
18 8.949 6.521 8.539 6.305 8.128 6.089 7.718 5.873 7.307 5.567 6.815 5.398
19 9.203 6.084 8.795 5.918 8.386 5.751 7.977 5.584 7.568 5.417 7.078 5.217
20 9.456 5.646 9.037 5.517 8.617 5.387 8.198 5.257 7.779 5.128 7.276 4.972
21 9.708 5.207 9.270 5.107 8.832 5.007 8.394 4.907 7.956 4.806 7.430 4.686
22 9.959 4.768 9.503 4.697 9.046 4.626 8.590 4.556 8.133 4.485 7.585 4.400
23 10.211 4.328 9.736 4.287 9.261 4.246 8.785 4.205 8.310 4.164 7.740 4.114
24 10.462 3.889 9.969 3.877 9.475 3.866 8.981 3.854 8.487 3.842 7.895 3.828
30
20 9.456 6.272 9.037 6.142 8.617 6.012 8.198 5.883 7.779 5.753 7.276 5.598
21 9.708 5.832 9.270 5.732 8.832 5.632 8.394 5.532 7.956 5.432 7.430 5312
22 9.959 5.393 9.503 5.322 9.046 5.252 8.590 5.181 8.133 5.110 7.585 5.026
23 10.211 4.954 9.736 4.913 9.261 4.871 8.785 4.830 8.310 4.789 7.740 4.739
24 10.462 4.515 9.969 4.503 9.475 4.491 8.981 4.479 8.487 4.468 7.895 4.453
Model: AWM 301R - ALC 28CR
Heating Mode
ID
WB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.527 3.527 4.422 4.422 4.720 4.720 8.000 8.000 9.790 9.790 10.684 10.684 11.579 11.579
17 3.437 3.437 4.332 4.332 4.630 4.630 7.939 7.939 9.523 9.523 10.386 10.386 11.250 11.250
19 3.347 3.347 4.241 4.241 4.540 4.540 7.877 7.877 9.256 9.256 10.088 10.088 10.920 10.920
21 3.256 3.256 4.151 4.151 4.449 4.449 7.816 7.816 8.989 8.989 9.790 9.790 10.591 10.591
23 3.252 3.252 4.082 4.082 4.359 4.359 7.461 7.461 8.722 8.722 9.492 9.492 10.262 10.262
25 3.247 3.247 7.014 7.014 4.269 4.269 7.105 7.105 8.455 8.455 9.194 9.194 9.932 9.932
27 3.242 3.242 3.945 3.945 4.179 4.179 6.750 6.750 8.188 8.188 8.896 8.896 9.603 9.603
FROST REGION
