Model : ALC 18 / 20C
No Descriptions Part No No Descriptions Part No
1 ASSY,PAN BASE (5SL20C/CR) R50014078281 13 PANEL TOP (SL20C/25C/28C/CR) R01014070596
ASSY,OUTDOOR COIL 7mm coil
MLC 018C R50024089940
MLC 020C R50024084570
3 BRACKET MOTOR (SL20C/CR) R01014070601
16 ASSY VALVE COVER (SL20C/CR) R50124072885
ASSY. CAP TUBE DIET COMP
MLC 018C R50024089926
MLC 020C R50024087066
18 PARTITION (SL20C/CR) R01014070603
7 PANEL RIGHT BACK (SL20C/CR) R01014070599
9 PANEL FRONT/LEFT (SL20C/CR) R01014070597
10 PANEL SERVICE (SL20C/CR) R01014070598
CAPACITOR, CMPSR 60uF/450V
Shizuki
R04029026782
12
ASSY CONTROL PANEL
(SL20C/25C)
R50044086133
R50054072863
ASSY,VALVE 2 WAY(1/4")JA28493-
1MA HANGJI
R50059022156
11
PANEL TERMINAL COVER
(SL20C/25C/28C/CR)
R01014070838
PLASTIC,HANDLE
SL07C/09C/10C/15C/CR
R12014057948
ASSY FLARE VALVE 3
WAY(5/8")SL20C/25C/28
R50014072861
8
COMPRESSOR, 2KS324D5AA04
Matsushita
R04019027266
14
ASSY FRONT GRILLE
(SL20C/25C/28C/CR)
R50124072880
15
FAN PROPELLER, ¥460 0Z40700
SUNWILL CHINA
R03019023393
6
ASSY VALVE BRACKET
(SL20C/CR)-R22
BACK GRILLE WITH PAINT
(SL18C/20C/CR)
R50019026515
2
17
Parts not showed in diagram
4
MOTOR, YDK64-6C/MSL25C-501-
WL
R03039024539
5
