Model : ALC 10 / 15C
No Descriptions Part No No Descriptions Part No
1 ASSY,PAN BASE SL10/15C R50014051158 14 ASSY,VALVE COVER R50124051173
2 ASSY,OUTDOOR COIL SL15C/CR R50024087838 PANEL,TOP/FRONT R01014051171
VALVE BRACKET R01014051164
Assy, 2 way flare valve 1/4" R50054054950
5 PARTITION R01014051165
9 PANEL,LEFT R01014051166 ASSY, O2 THERAPHY R50044070393
10 PANEL,RIGHT R01014051167 ASSY, PARTITION O2 R50064070384
11 BRACKET,FAN MOTOR R01014051162
R50124056700
FAN PROPELLER, DIA401.0
OZ42000 SHUNDE
R03019015339
3
COMPRESSOR, 2PS206D2AF02
MATSUSHITA
R04019027709 ASSY,FRONT GRILLE (SL10C/15C)
15
4
8
ASSY,SUCTION TUBE (SL15C)
(2PS206D2AF02)
R50024087761
6
ASSY,CAPILLARY TUBE (SL15C)
2PS206D2AF02
R50024087757
7
ASSY.,TUBE DISCHARGE
SL15C(2PS206D2AF02)
13
ASSY,CONTROL PANEL
SL09C/10C/5SL15C
R50044086056
16
12
MOTOR, MSL15C-501 24W
B.OCEAN
R03039015323
R50024087928
Parts not showed in diagram
CAPACITOR, CMPSR 2uF/450
(TAB187)Shizuki
R04029026755
AIR FILTER, OXYGEN
ENRICHMENT MEMBRANE
R03089020671
CAPACITOR, CMPSR 35uF/450VAC
Shizuki
R04029026776
CAPACITOR, CMPSR 30uF/450VAC
Shizuki
R04029026775
PUMP, O2 ENRICHMT VACUM DAL
-
12S-04 ULVAC
R04139020673
CAPACITOR, E 0.9µF 480V +10-5%
50/60Hz
R04029020674
