1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
General Data - Cooling Only (R22)
MWM 025G MWM 030F
MLC 025C MLC 028C
Btu/h 23,500 27000
W 6,890 7913
W
2,530 2732
A 11.3 13.1
V/Ph/Hz
W/W 2.72 2.89
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
HIGH l/s / cfm 297 / 630 316 / 670
MEDIUM l/s / cfm 231 / 490 297 / 630
LOW l/s / cfm
208 / 440 236 / 500
dBA 49 / 44 / 42 49 / 47 / 45
HEIGHT mm/in
304 / 12.0 360 / 14.2
WIDTH mm/in 1062 / 41.8 1200 / 47.2
DEPTH mm/in
222 / 8.7 200 / 7.9
HEIGHT mm/in 378 / 14.9 420 / 16.5
WIDTH mm/in
1130 / 44.5 1267 / 49.9
DEPTH mm/in 292 / 11.5 260 / 10.2
kg/lb
16 / 35.27 17 / 37.48
mm/in
l/s / cfm
755 / 1600 632 / 1340
dBA 52 54
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
62 / 136.7 68 / 149.9
LIQUID mm/in
GAS mm/in
kg/lb
1.5 / 3.3 2.1 / 4.63
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL (H/M/L)
AIR FLOW
OPERATION
EER
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
CONTROL
AIR DISCHARGE
220-240 /1/50
LCD REMOTE CONTROL
20 / 0.79
9.52 / 3/8
R22
750 / 29.5
855 / 33.7
328 / 12.9
810 / 31.9
OUTDOOR CAP. TUBE
990 / 39.0
415 / 16.3
FLARE VALVE
15.88 / 5/8
AWM 25G AWM 311
ALC 25C ALC 28C
