Acson AWM 25GR

151
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 10/15CR
No Description Part Number
1 Assy. Base Pan R50014051158
2 Assy. Outdoor Coil
A5LC 10CR R50024083859
A5LC 15CR R50024084998
3 Valve Bracket R01014051164
4 Compressor
A5LC 10CR R04019019590
A5LC 15CR R04019026326
5 Assy. Partition R50064055063
6 Assy. Cap Tube
A5LC 10CR R50024083856
A5LC 15CR R50024084738
7 Bracket, Fan Motor R01014051162Y
8 Fan Motor
ALC 10CR R03039016104
ALC 15CR R03039015323
9 Fan Propeller R03019015339
10 Left Panel R01014051166Y
11 Right Panel R01014051167Y
No Description Part Number
12 Top/Front Panel R01014051171Y
13 Assy. Control Panel
A5LC 10CR R50044086065
A5LC 15CR R50044086066
14 Assy. Valve Cover R50124051173
15 Assy. Front Grille R50124093630
16 Plastic Handle R12014057948
17 Assy. 2 Ways Valve 1/4” R50059030514
18 Assy. 3 Ways Valve 3/8”
A5LC 10CR R50059030505
Assy. 3 Ways Flare Valve
1/2”
A5LC 15CR R50059030476
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor
A5LC 10CR R04029026774
A5LC 15CR R04029026776
Valve, Rev 4 Way R05019016936
Defrost Thermistor R50134039416
